订购号 | Ød | Ød1 | Ød2 | L | L1 | L2 | 刀具夹持 |
HSK40E-CR04-105 | 4 | 16 | 23 | 105 | 85 | 40 | 18 |
HSK40E-CR06-105 | 6 | 20 | 27 | 105 | 85 | 40 | 25.5 |
HSK40E-CR08-105 | 8 | 20 | 27 | 105 | 85 | 40 | 25.5 |
HSK40E-CR10-105 | 10 | 24 | 32 | 105 | 85 | 47 | 31.5 |
HSK40E-CR12-105 | 12 | 24 | 32 | 105 | 100 | 47 | 36.5 |
|
|
|
|
|
|
|
|
HSK50E-CR04-135 | 4 | 16 | 23 | 135 | 109 | 40 | 18 |
HSK50E-CR06-135 | 6 | 20 | 27 | 135 | 109 | 40 | 25.5 |
HSK50E-CR08-135 | 8 | 20 | 27 | 135 | 109 | 40 | 25.5 |
HSK50E-CR10-135 | 10 | 24 | 32 | 135 | 109 | 47 | 31.5 |
HSK50E-CR12-135 | 12 | 24 | 32 | 135 | 139 | 47 | 36.5 |
